GV Pneumatic Configurator

Indicates a required attribute.

Base Product Selection:

Bore (in) 2-1/2 3-1/4 4 5 6 8 10 12 14 16 18 20 22 24

Rod Style Single Double

Stroke (in) (1/8" Increments)

Options and Accessories
Rod Material Standard 174	Seal Material Standard F	Rod Extension W WD WF WR	Tie Rod Extension (Rod end) Yes	Tie Rod Extension (Cap end) Yes

Rod Extension Length (in) 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00 6.25 6.50 6.75 7.00 7.25 7.50 7.75 8.00 8.25 8.50 8.75 9.00 9.25 9.50 9.75 10.00 10.25 10.50 10.75 11.00 11.25 11.50 11.75 12.00

Rod Extension Length (rear) (in) 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00 6.25 6.50 6.75 7.00 7.25 7.50 7.75 8.00 8.25 8.50 8.75 9.00 9.25 9.50 9.75 10.00 10.25 10.50 10.75 11.00 11.25 11.50 11.75 12.00

Tie Rod Extension Length (Rod end) (in) 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00

Tie Rod Extension Length (Cap end) (in) 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 5.25 5.50 5.75 6.00

Aluminum Components - 2-1/2" through 12" Bore The end plates and piston are made from high strength Alumnium. Combined with an Aluminum or composite cylinder tube the ITT GV actuators are over 50% lighter than actuators constructed from steel components. The end plates are black hard coat anodized for high corrosion and abrasion resistance.
Wear Band Piston Piston includes a wear band to support the weight of the piston and rod assembly as well as to handle side loading. The wear band also serves to prevent the over compression of the piston seal and practically eliminates compression set of the piston seal during long idle periods.	End plates with rounded corners All end plates have rounded versus sharp corners to minimize the potential for injury when handling the actuator.
